Description
Features
High Precision
Wide Attenuation Range
Excellent Stability and Reliability
Applications
Optical Communication Systems
Fiber Instrument
CATV Networks
In Line Fixed Optical Attenuator (FOA)-2000nm
Specifications
| Parameters | Unit | Values | ||
| Operating Wavelength | nm | 1950, 2000, 2050 | ||
| Operating Bandwidth | nm | ±50 | ||
| Attenuation Range | dB | 1dB, 3dB,5dB, 7dB, 10dB, 15dB, 20dB, etc | ||
| Attenuation Precision | dB | ±10% Attenuate Value | ||
| Pigtail Type | 250μm | 900μm | 2mm or 3mm | |
| Package Size | mm | φ3.0x40;φ3.0x54; | φ3.0x54;90x16x9; | φ4.0x75;90x16x9; |
| Fiber Length | 1m, others on request | |||
| Fiber Type | SMF-28 or SM1950 | |||
| Power Handling (CW) | W | 0.5, 1, 3, 5, 10 | ||
| Operating Temperature | ℃ | -40 ~ +85 | ||
| Storage Temperature | ℃ | -40 ~ +85 | ||
Ordering Information
| Type | I=In-Line; |
| Wavelength | 1950; 2000; 2050; |
| Attenuation | 1=1dB; 3=3dB; 5=5dB; 10=10dB; 15=15dB; 20=20dB; XX=Specity; |
| Pigtail Type | 250=250µm Fiber; 900=900µm Loose Tube; 2mm=2mm loose tube; 3mm=3mm Loose Tube; |
| Fiber Type | 1=SMF-28e; 7=SM1900; |
| Length | 1= 1m; X=Other; |
| Connector | NE=None; FA=FC/APC; FC=FC/UPC; SA=SC/APC; SC=SC/UPC; LC=LC/UPC; XX=Others; |
| Package | 3x40; 3x54; 4x75; 90x16x9; |
| Power Handling | 0.5W; 1W; 3W; 5W; 10W; |
