Description
Features
High Stability and Reliability
Length Customized Grating
High SLSR
Application
FBG Sensors
Grating Measurement
FBG for Sensor
Specifications
| Parameters | Unit | Values | |||
| Center Wavelength | nm | 1510~1650 | |||
| FBG Profile | Apodized | ||||
| Wavelength Tolerance | nm | ±0.3 | |||
| FBG Length | mm | 3 | 5 | 10 | 15 |
| Reflectivity | ≥70% | ≥75% | ≥90% | ≥90% | |
| Bandwidth at 3dB | nm | ≤0.7 | ≤0.7 | ≤0.3 | ≤0.3 |
| SLSR | dB | ≥15 | |||
| Recoating | Acrylate Or Polyimide | ||||
| Proof Test | Kpsi | ≥100 | |||
| Fiber Type | SMF-28e Or Polyimide Fiber | ||||
| Fiber Termination | Bare Fiber, FC/UPC, FC/APC or E2000 | ||||
| Fiber Length | m | 1 (Typical) | |||
| Operating Temperature | ℃ | SMF-28 Fiber: -5 ~ 80 | |||
| Polyimide Fiber: -40 ~ 300 | |||||
| Storage Temperature | ℃ | SMF-28 Fiber: -40 ~ 80 | |||
| Polyimide Fiber: -40 ~ 300 | |||||
| Wavelength | 1510; 1520; … |
| Fiber Type | SMF-28e; Polyimide; |
| FBG length | 03=3mm; 05=5mm; 10=10mm; 15=15mm |
| Recoating Type | A=Acrylate; P=Polyimide; |
| Fiber Length | 1=1m; 2=2m; … |
